PICK YOUR DESTINATION AND FIND JOY IN THE JOURNEY. THIS VERSATILE ALL-ROUNDER E-BIKE IS IDEAL FOR TREKKING, COMMUTING OR RIDING OR SIMPLY BOOSTING THE FUN FACTOR ON ANY RIDE.
KEY PERFORMANCE FACTORS
Overall stability
The ALUXX aluminum frameset and SyncDrive Life motor combine for smooth handling and acceleration on all types of roads from hills to flats.
Explore new routes
The RideControl EVO with on-board navigation helps riders find their way, and smartphone connectivity makes it easy to keep the battery charged.
Longer range
Explore E+ gives riders the freedom to ride farther with its EnergyPak Smart battery that delivers 500Wh of power.
RANGE
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
ENERGYPAK SMART 500 / SYNCDRIVE SPORT
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
-
- S
- 5’4”
5’8”
-
- M
- 5’7” 5’10”
-
- L
- 5’9” 6’1”
-
- XL
- 6’0” 6’4”
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (inch) | 17.1 | 19.1 | 21.1 | 23 |
| B | SEAT TUBE ANGLE | 74.0° | 73.0° | 73.0° | 73.0° |
| C | TOP TUBE LENGTH (inch) | 22.4 | 23.2 | 24 | 24.8 |
| D | HEAD TUBE LENGTH (inch) | 5.1 | 5.5 | 6.1 | 6.7 |
| E | HEAD TUBE ANGLE | 69.5° | 69.5° | 69.5° | 69.5° |
| F | FORK RAKE (inch) | 1.7 | 1.7 | 1.7 | 1.7 |
| G | TRAIL (inch) | 3.6 | 3.6 | 3.6 | 3.6 |
| H | WHEELBASE (inch) | 43.8 | 44.1 | 45 | 45.8 |
| I | CHAIN STAY LENGTH (inch) | 17.9 | 17.9 | 17.9 | 17.9 |
| J | BOTTOM BRACKET DROP (inch) | 2.4 | 2.4 | 2.4 | 2.4 |
| K | STACK (inch) | 24 | 24.4 | 24.9 | 25.5 |
| L | REACH (inch) | 15.6 | 15.7 | 16.4 | 17 |
| M | STAND OVER HEIGHT (inch) | 29.3 | 30.5 | 31.8 | 33.2 |
| N | HANDLEBAR WIDTH (inch) | 27.2 | 27.2 | 27.2 | 27.2 |
| O | STEM LENGTH (inch) | 2.4 | 2.8 | 3.1 | 3.5 |
| P | CRANK LENGTH (inch) | 6.7 | 6.7 | 6.7 | 6.7 |
| Q | WHEEL SIZE | 700C | 700C | 700C | 700C |
