GET YOUR DAILY DOSE OF SINGLETRACK. WITH A LIGHTWEIGHT FRAME, 130MM SUSPENSION FORK AND 27.5 WHEELS WITH HIGH-VOLUME TIRES, THIS HARDTAIL OFFERS LOADS OF TRACTION, SPEED AND FUN ON THE TRAIL.
KEY PERFORMANCE FACTORS
Trail tuned design
Balanced geometry with a 75-degree seattube angle puts the rider in a powerful pedaling position on climbs, while a slacker 66-degree head angle boosts confidence and control on technical descents.
Responsive handling
Lightweight ALUXX SL aluminum hardtail frame offers agile acceleration and maneuverability to help riders climb, corner and hammer the flats with efficiency and speed.
Smooth control
Giant Crest 34 suspension fork with 130mm of travel absorbs roots, rocks and ruts. Grippy, high-volume tires boost traction on rugged terrain. And a dropper seatpost with handlebar remote lets you adjust saddle height on the fly for confident positioning on changing terrain.
-
SizesS, M, L, XL
-
ColorsKnight Shield
-
FrameALUXX SL-Grade Aluminum
-
ForkGiant Crest 34 SL RCL, 130mm, 44mm offset, Boost 15×110
-
ShockN/A
-
HandlebarGiant Contact TR35, 780x35mm
-
GripsGiant Sole-O
-
StemGiant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
-
SeatpostGiant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M: 125mm travel / 30.9 x 395mm L: 150mm travel / 30.9 x 440mm XL: 170mm travel / 30.9 x 450mm
-
SaddleGiant Romero
-
Pedalsplatform [GC,GT]
-
ShiftersSRAM SX Eagle, 1×12
-
Front DerailleurN/A
-
Rear DerailleurSRAM NX Eagle
-
BrakesShimano BR-MT420/410, hydraulic, Shimano RT-26 rotors [F]180mm, [R]180mm
-
Brake LeversShimano BR-MT401
-
CassetteSRAM SX Eagle, 11×50
-
ChainSRAM SX Eagle
-
CranksetSRAM SX Eagle, 30t S:165mm, M:170mm, L:170mm, XL:170mm
-
Bottom BracketSRAM DUB, press fit
-
RimsGiant AM 27.5, tubeless ready sleeve-joint rim, 30mm inner width
-
Hubsalloy, sealed
-
Spokesstainless
-
TiresMaxxis Ardent Race 27.5×2.6, folding, TR
-
Extrastubeless prepared, 2.6″ max tire size, 32t max chainring size
-
WeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
-
- S
- 5’4”
5’8”
-
- M
- 5’7” 5’11”
-
- L
- 5’10” 6’2”
-
- XL
- 6’2” 6’6”
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (inch) | 15 | 16.9 | 18.3 | 19.5 |
| B | SEAT TUBE ANGLE | 75.0° | 75.0° | 75.0° | 75.0° |
| C | TOP TUBE LENGTH (inch) | 23.3 | 24.1 | 25.2 | 26.1 |
| D | HEAD TUBE LENGTH (inch) | 3.7 | 3.7 | 4.1 | 4.5 |
| E | HEAD TUBE ANGLE | 66.0° | 66.0° | 66.0° | 66.0° |
| F | FORK RAKE (inch) | 1.7 | 1.7 | 1.7 | 1.7 |
| G | TRAIL (inch) | 4.4 | 4.4 | 4.4 | 4.4 |
| H | WHEELBASE (inch) | 45.4 | 46.2 | 47.4 | 48.3 |
| I | CHAIN STAY LENGTH (inch) | 17.1 | 17.1 | 17.1 | 17.1 |
| J | BOTTOM BRACKET DROP (inch) | 2.4 | 2.4 | 2.4 | 2.4 |
| K | STACK (inch) | 24.5 | 24.5 | 24.8 | 25.2 |
| L | REACH (inch) | 16.7 | 17.5 | 18.5 | 19.3 |
| M | STAND OVER HEIGHT (inch) | 28 | 28.6 | 29.4 | 30.4 |
| N | HANDLEBAR WIDTH (inch) | 30.7 | 30.7 | 30.7 | 30.7 |
| O | STEM LENGTH (inch) | 1.6 | 1.6 | 2 | 2 |
| P | CRANK LENGTH (inch) | 6.5 | 6.7 | 6.7 | 6.7 |
| Q | WHEEL SIZE | 27.5″ | 27.5″ | 27.5″ | 27.5″ |
