EVERY TRAIL, EVERY STEEP CLIMB, EVERY THRILLING DESCENT. TESTED AND DEVELOPED BY GIANT’S E-BIKE ENDURO PROS, THIS UPDATED TRAIL RIPPER GIVES YOU THE POWER TO ENJOY THE BEST PARTS OF THE RIDE AGAIN AND AGAIN.
KEY PERFORMANCE FACTORS
Trail technology
Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor technology boost your capabilities on steep climbs and rugged descents.
Total control
RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App gives you tuning options and E-bike specific fitness tracking.
Long-lasting power
Climb steep mountains and enjoy fun descents all day long with the downtube-integrated EnergyPak
RANGE
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
ENERGYPAK SMART 625 / SYNCDRIVE PRO
HIGHLIGHTS
A 29-inch front wheel and 27.5-inch rear wheel work together to offer superior handling and agility on technical terrain. The updated frameset features new geometry with a shorter rear end and longer reach. New control units include RideControl Go, which is integrated into the top tube, and RideControl Ergo 3, attached to the handlebar near the grip. A new flip chip feature lets you adjust frame geometry for riding style and terrain.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
| S | M | L | XL | ||
|---|---|---|---|---|---|
| LOWÂ |Â HIGH | LOWÂ |Â HIGH | LOWÂ |Â HIGH | LOWÂ |Â HIGH | ||
| A | SEAT TUBE LENGTHÂ (inch) | 15.7 | 16.7 | 17.7 | 18.7 |
| B | SEAT TUBE ANGLE | 76.7° | 77.5° | 76.7° | 77.5° | 76.7° | 77.5° | 76.7° | 77.5° |
| C | TOP TUBE LENGTHÂ (inch) | 22.4Â |Â 22.4 | 23.4Â |Â 23.4 | 24.5Â |Â 24.4 | 25.6Â |Â 25.5 |
| D | HEAD TUBE LENGTHÂ (inch) | 3.9 | 3.9 | 4.3 | 4.7 |
| E | HEAD TUBE ANGLE | 63.7° | 64.5° | 63.7° | 64.5° | 63.7° | 64.5° | 63.7° | 64.5° |
| F | FORK RAKEÂ (inch) | 1.7 | 1.7 | 1.7 | 1.7 |
| G | TRAILÂ (inch) | 5.3Â |Â 5.2 | 5.3Â |Â 5.2 | 5.3Â |Â 5.2 | 5.3Â |Â 5.2 |
| H | WHEELBASEÂ (inch) | 47.6Â |Â 47.6 | 48.7Â |Â 48.7 | 49.8Â |Â 49.8 | 51Â |Â 51 |
| I | CHAIN STAY LENGTHÂ (inch) | 17.9Â |Â 17.9 | 17.9Â |Â 17.9 | 17.9Â |Â 17.9 | 17.9Â |Â 17.9 |
| J | BOTTOM BRACKET DROPÂ (inch) | 1Â |Â 0.6 | 1Â |Â 0.6 | 1Â |Â 0.6 | 1Â |Â 0.6 |
| K | STACKÂ (inch) | 25Â |Â 24.9 | 25Â |Â 24.9 | 25.4Â |Â 25.2 | 25.7Â |Â 25.6 |
| L | REACHÂ (inch) | 16.7Â |Â 16.9 | 17.7Â |Â 17.9 | 18.7Â |Â 18.9 | 19.7Â |Â 19.9 |
| M | STAND OVER HEIGHTÂ (inch) | 30.9Â |Â 31.1 | 30.4Â |Â 30.6 | 30.4Â |Â 30.5 | 30.2Â |Â 30.4 |
| N | HANDLEBAR WIDTHÂ (inch) | 31.5 | 31.5 | 31.5 | 31.5 |
| O | STEM LENGTHÂ (inch) | 1.6 | 1.6 | 2 | 2 |
| P | CRANK LENGTHÂ (inch) | 6.3 | 6.3 | 6.5 | 6.5 |
| Q | WHEEL SIZE | F29″ / R27.5″ | F29″ / R27.5″ | F29″ / R27.5″ | F29″ / R27.5″ |
