TRAINING, RACING, PUSHING IT TO THE LIMIT. WHETHER YOU’RE ATTACKING THE FIELD OR DIGGING DEEP FOR A NEW PR, THE NEW TCR ADVANCED DISC IS LIGHTER, STIFFER AND FASTER WITH STRATEGIC AERO TUBE SHAPING, ADDED TIRE CLEARANCE AND INTEGRATED DISC BRAKE TECHNOLOGY.

Reengineered with updated aerodynamic tube shaping in the headtube, downtube and fork, plus added clearance for larger diameter tires (up to 32mm), the new TCR Advanced Disc delivers outstanding on-the-road efficiency. The Variant seatpost adds just enough compliance to give it a balanced, race-tuned feel on the road. And with its integrated disc-brake technology, including flat mounts and 12mm front and rear thru-axles, it’s an all-weather, all-conditions race machine to keep you at the front of the pack.

KEY PERFORMANCE FACTORS

Class-leading efficiency

With an impressive stiffness-to-weight ratio and updated aero tube shaping, this frameset is engineered to give road racers and riders superior climbing capabilities, aerodynamic efficiency and sprint stiffness for race-winning performance.

Advanced aerodynamics

This is where the TCR’s most quantifiable gains can be found compared to previous generation models. Every tube shape was analyzed, engineered and tested to create an overall structure with significantly lower drag at a wider range of yaw angles. The result is a TCR that’s faster than ever in sprints and solo situations.

Total control

Integrated disc brakes deliver smooth, powerful stopping power and modulation for added control in variable weather and road conditions. Flat mounts and new thru-axles boost stiffness and improve overall handling, while added frame and fork clearance allows for larger diameter tires up 32mm.

Specs

Sizes

XS, S, M, ML, L, XL
Colors

Matte Carbon/Gloss Rainbow Black, White
Frame

Advanced-Grade Composite, disc
Fork

Advanced-Grade Composite, OverDrive steerer, disc
Shock

N/A
Handlebar

Giant Contact
Stem

Giant Contact
Seatpost

Giant Variant, composite
Saddle

Giant Approach, UniClip accessory mount
Pedals

N/A
Shifters

Shimano 105
Front Derailleur

Shimano 105
Rear Derailleur

Shimano 105
Brakes

Giant Approach, UniClip accessory mount
Brake Levers

Shimano 105 hydraulic
Cassette

Shimano 105, 11-speed, 11×30
Chain

KMC X11EL-1
Crankset

Shimano RS510, 36/52
Bottom Bracket

Shimano, press fit
Rims

Giant PR-2 Disc wheelset
Hubs

Giant PR-2 Disc wheelset, 12mm thru-axle
Spokes

Sapim Race
Tires

Giant Gavia Course 1, tubeless, 700x25c, folding
Weight

The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
