FAST STARTS, TIGHT CORNERS, A BLUR OF SPEED THROUGH DIRT, SAND AND MUD. PROVEN BY ELITE CYCLOCROSS PROS FOR YEARS, THE LATEST TCX ADVANCED PRO IS BUILT TO WIN.
KEY PERFORMANCE FACTORS
Elite level efficiency
Advanced-grade composite frameset is 17.5 percent lighter than the previous generation while retaining its best-in-class torsional/pedaling stiffness.
Total control
Integrated disc brake technology with flat mounts and thru-axle hubs, combined with tubeless ready Giant WheelSystem, delivers added control in variable conditions and all types of weather.
Smooth ride quality
D-Fuse composite seatpost helps absorb bumps and vibrations, and you also have the option to switch to a standard 30.9mm round or dropper post depending on your riding style and terrain.
HIGHLIGHTS
The superlight composite frame is handcrafted with race-proven geometry and asymmetrical chainstays for optimal power transfer. The D-Fuse composite seatpost helps smooth out bumps and vibrations, and you also have the option to use a 30.9mm round standard or dropper seatpost. Other innovations include a lightweight composite WheelSystem and tubeless tires right out of the box; flat-mount disc brakes; and 12mm front and rear thru-axles for total control and fast cornering, sprinting and climbing in all conditions.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
| S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTHÂ (inch) | 19.9 | 20.7 | 21.5 | 21.9 | 22.2 |
| B | SEAT TUBE ANGLE | 73.5° | 73.0° | 73.0° | 73.0° | 73.0° |
| C | TOP TUBE LENGTHÂ (inch) | 20.9 | 21.5 | 22 | 22.6 | 23.2 |
| D | HEAD TUBE LENGTHÂ (inch) | 5.2 | 5.8 | 6.4 | 7 | 7.6 |
| E | HEAD TUBE ANGLE | 71.0° | 71.5° | 72.0° | 72.5° | 72.5° |
| F | FORK RAKEÂ (inch) | 2 | 2 | 2 | 2 | 2 |
| G | TRAILÂ (inch) | 2.7 | 2.6 | 2.4 | 2.3 | 2.3 |
| H | WHEELBASEÂ (inch) | 39.9 | 40.2 | 40.6 | 40.9 | 41.5 |
| I | CHAIN STAY LENGTHÂ (inch) | 16.9 | 16.9 | 16.9 | 16.9 | 16.9 |
| J | BOTTOM BRACKET DROPÂ (inch) | 2.4 | 2.4 | 2.4 | 2.4 | 2.4 |
| K | STACKÂ (inch) | 20.7 | 21.9 | 22.5 | 23.2 | 23.7 |
| L | REACHÂ (inch) | 14.6 | 14.8 | 15.2 | 15.6 | 16 |
| M | STAND OVER HEIGHTÂ (inch) | 31 | 31.8 | 32.5 | 32.8 | 33.3 |
| N | HANDLEBAR WIDTHÂ (inch) | 15.7 | 16.5 | 16.5 | 17.3 | 17.3 |
| O | STEM LENGTHÂ (inch) | 3.1 | 3.5 | 3.9 | 3.9 | 4.3 |
| P | CRANK LENGTHÂ (inch) | 6.7 | 6.8 | 6.8 | 6.9 | 6.9 |
| Q | WHEEL SIZE | 700C | 700C | 700C | 700C | 700C |
