CHUNKY ROCK GARDENS, ROOTS AND TECHNICAL CLIMBS. THIS HARD-CHARGING TRAIL BIKE ADAPTS TO THE TERRAIN, GIVING YOU CONFIDENCE AND CONTROL ON ALL TYPES OF SINGLETRACK.
KEY PERFORMANCE FACTORS
29er confidence and control
29-inch wheels optimized to roll over technical terrain with balance and stability, giving you more momentum on tricky climbs and confidence to fly on fast singletrack descents. Added clearance for up to 2.5-inch tires.
Progressive suspension
Maestro rear suspension features a trunnion mount shock with a longer stroke and smoother feel. With 135mm of full rear-wheel travel (and 150mm up front), it features an Advanced Forged Composite upper rocker arm for increased stiffness and strength plus lower overall frame weight.
Adjustable geometry
A flip chip lets you change the headtube and seattube angles, along with the bottom bracket height, to fine-tune the handling. You can choose the low position (65.5/77.2 head/seattube angle and 40mm BB drop) for fast, open terrain, or high (66.2/77.9 head/seattube angle and 30mm drop) for slower, tighter singletrack.
HIGHLIGHTS
Engineered to help you ride faster and smoother on the toughest trails, this versatile trail bike has a lightweight, strong and stiff aluminum chassis with 29er-specific geometry. Updated Maestro rear suspension delivers 135mm of active rear travel that pairs perfectly with a 150mm fork. The Advanced Forged Composite rocker arm has a flip chip that allows you to adjust frame geometry. Choose steeper or slacker headtube/seattube angles and either a 30mm or 40mm bottom bracket drop to adjust the handling for your riding style and terrain.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
| S | M | L | XL | ||
|---|---|---|---|---|---|
| LOWÂ |Â HIGH | LOWÂ |Â HIGH | LOWÂ |Â HIGH | LOWÂ |Â HIGH | ||
| A | SEAT TUBE LENGTHÂ (inch) | 16.9 | 16.9 | 18.3 | 19.5 |
| B | SEAT TUBE ANGLE | 77.2° | 77.9° | 77.2° | 77.9° | 77.2° | 77.9° | 77.2° | 77.9° |
| C | TOP TUBE LENGTHÂ (inch) | 22.3Â |Â 22.2 | 23.5Â |Â 23.4 | 24.8Â |Â 24.7 | 25.8Â |Â 25.7 |
| D | HEAD TUBE LENGTHÂ (inch) | 3.7 | 3.9 | 4.3 | 4.7 |
| E | HEAD TUBE ANGLE | 65.5° | 66.2° | 65.5° | 66.2° | 65.5° | 66.2° | 65.5° | 66.2° |
| F | FORK RAKEÂ (inch) | 1.7 | 1.7 | 1.7 | 1.7 |
| G | TRAILÂ (inch) | 4.9Â |Â 4.7 | 4.9Â |Â 4.7 | 4.9Â |Â 4.7 | 4.9Â |Â 4.7 |
| H | WHEELBASEÂ (inch) | 46.2 | 47.4 | 48.8 | 49.9 |
| I | CHAIN STAY LENGTHÂ (inch) | 17.2 | 17.2 | 17.2 | 17.2 |
| J | BOTTOM BRACKET DROPÂ (inch) | 1.6 | 1.6 | 1.6 | 1.6 |
| K | STACKÂ (inch) | 24.3 | 24.4 | 24.8 | 25.2 |
| L | REACHÂ (inch) | 16.8 | 18 | 19.1 | 20.1 |
| M | STAND OVER HEIGHTÂ (inch) | 28.9 | 28.7 | 29.7 | 30.6 |
| N | HANDLEBAR WIDTHÂ (inch) | 30.7 | 30.7 | 30.7 | 30.7 |
| O | STEM LENGTHÂ (inch) | 1.6 | 1.6 | 2 | 2 |
| P | CRANK LENGTHÂ (inch) | 6.5 | 6.7 | 6.7 | 6.7 |
| Q | WHEEL SIZE | 29″ | 29″ | 29″ | 29″ |
