FROM PARKWAYS TO PATHS AND EVERYTHING IN BETWEEN, THIS VERSATILE BIKE CAN ADD SOME SPICE TO YOUR COMMUTE OR FITNESS ROUTINE. WITH ITS FLAT HANDLEBAR, UPRIGHT POSITIONING AND SUSPENSION FORK, YOU’RE FREE TO RIDE DIFFERENT TYPES OF TERRAIN WITH CONFIDENCE AND CONTROL.
With a rugged personality and a smooth riding style, ATX features the familiar flat handlebar look of a traditional mountain bike. It has a lightweight yet durable ALUXX aluminum frame and a suspension fork with 100 mm of smooth travel to soak up bumps. The wheel diameter varies based on bike size, with 26-inch wheels on smaller frames and 27.5 on larger ones. This tailors the bike’s handling to a rider’s height. Powerful brakes deliver confident handling in all types of weather, and integrated mounts make it easy to add racks or fenders to suit your riding adventures.
KEY PERFORMANCE FACTORS
All-terrain versatility
With a mountain bike-style flat handlebar, suspension fork and powerful brakes, you can ride road or dirt with confidence.
Lightweight and durable
Frameset constructed with high-quality ALUXX aluminum.
Comfort and stability
Frame geometry puts the rider in a position that balances efficiency with stability on rough roads, paths or trails.
Specs
-
Sizes26: XXS,XS,S 27.5: S,M,L,XL
-
ColorsVibrant Blue, Black
-
FrameALUXX-Grade Aluminum
-
ForkSR Suntour M3030A, 75mm, coil spring, QR, preload adjust
-
ShockN/A
-
HandlebarGiant Sport, 25.4
-
StemGiant Sport
-
SeatpostGiant Sport, 30.9
-
SaddleGiant Sport Custom
-
PedalsPlatform
-
ShiftersShimano EF41
-
Front DerailleurShimano Tourney
-
Rear DerailleurShimano Tourney
-
Brakeslinear pull, alloy
-
Brake LeversShimano EF41
-
CassetteShimano TZ500, 7-speed, 14×34
-
ChainKMC Z7
-
CranksetProWheel forged alloy, 24/34/42
-
Bottom Bracketcartridge
-
RimsGiant CH17, alloy
-
Hubsalloy, sealed bearing
-
SpokesStainless
-
TiresGiant Quickcross, 26×2.2 or 27.5×2.2
-
WeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
HIGHLIGHTS
With a rugged personality and a smooth riding style, ATX features the familiar flat handlebar look of a traditional mountain bike. It has a lightweight yet durable ALUXX aluminum frame and a suspension fork with 100mm of smooth travel to soak up bumps. The wheel diameter varies based on bike size, with 26-inch wheels on smaller frames and 27.5 on larger ones. This tailors the bike’s handling to a rider’s height. Additionally, integrated mounts make it easy to add racks or fenders to suit your riding adventures.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
-
- XXS (26″)
- 5’0”
5’2”
-
- XS (26″)
- 5’2” 5’4”
-
- S (27.5″)
- 5’4” 5’7”
-
- M (27.5″)
- 5’7” 5’9”
-
- L (27.5″)
- 5’9” 6’1”
-
- XL (27.5″)
- 6’1” 6’4”
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
| XXS (26″) | XS (26″) | S (27.5″) | M (27.5″) | L (27.5″) | XL (27.5″) | ||
|---|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (inch) | 13.8 | 15.2 | 16.5 | 17.9 | 19.9 | 21.1 |
| B | SEAT TUBE ANGLE | 73.5° | 73.5° | 73.5° | 73.0° | 73.0° | 73.0° |
| C | TOP TUBE LENGTH (inch) | 21.9 | 22.2 | 22.6 | 23.2 | 24 | 24.8 |
| D | HEAD TUBE LENGTH (inch) | 3.7 | 4.1 | 3.7 | 4.3 | 5.7 | 6.7 |
| E | HEAD TUBE ANGLE | 68.0° | 68.0° | 68.0° | 68.0° | 68.0° | 68.0° |
| F | FORK RAKE (inch) | 1.7 | 1.7 | 1.7 | 1.7 | 1.7 | 1.7 |
| G | TRAIL (inch) | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 |
| H | WHEELBASE (inch) | 41.9 | 42.4 | 42.5 | 43 | 43.9 | 44.7 |
| I | CHAIN STAY LENGTH (inch) | 16.5 | 16.5 | 17.1 | 17.1 | 17.1 | 17.1 |
| J | BOTTOM BRACKET DROP (inch) | 1.4 | 1.4 | 2 | 2 | 2 | 2 |
| K | STACK (inch) | 21.9 | 22.2 | 22.9 | 23.4 | 24.7 | 25.6 |
| L | REACH (inch) | 15.4 | 15.7 | 15.9 | 16.1 | 16.5 | 17 |
| M | STAND OVER HEIGHT (inch) | 27.1 | 28 | 28.4 | 29.4 | 31.1 | 32 |
| N | HANDLEBAR WIDTH (inch) | 24.4 | 26 | 26 | 26 | 27.6 | 27.6 |
| O | STEM LENGTH (inch) | 2 | 2 | 2.8 | 2.8 | 3.5 | 3.5 |
| P | CRANK LENGTH (inch) | 6.3 | 6.5 | 6.7 | 6.7 | 6.9 | 6.9 |
| Q | WHEEL SIZE | 26″ | 26″ | 27.5″ | 27.5″ | 27.5″ | 27.5″ |
