FROM CITY STREETS TO RUGGED BACKROADS, THIS VERSATILE DROP-BAR E-BIKE GIVES YOU THE POWER TO VENTURE FAR ON GRAVEL ROADS, DIRT ROADS, ANY ROUTE YOU DREAM UP.
This new E-bike gives you the power to ride from suburban streets to rugged rural backroads with efficiency and control. It’s a great way to experience adventure on ever-changing terrain and feel the freedom to extend your range. The ALUXX SL aluminum frameset has a SyncDrive Pro motor that’s powered by Yamaha. This advanced system delivers smooth acceleration on paved roads, gravel or dirt. It also includes wider tires and integrated rack mounts so you can customize your adventure with fenders, racks or whatever other adventure accessories you need.
KEY PERFORMANCE FACTORS
Unlimited adventure
Powerful SyncDrive Pro motor, lightweight ALUXX SL aluminum frame, smooth-riding tubeless tires and a comfortable D-Fuse seatpost give you the ability to ride any road, any route.
Powerful, integrated battery
All-new EnergyPak Smart Compact 500 battery delivers long-distance pedaling support and is seamlessly integrated into the frame for a sleek overall profile.
System simplicity
With the press of the simple RideControl Switch on/off button on the top tube, you are ready to go. The SmartAssist mode will keep you spinning without any worries. ANT+ capability further allows you to connect a cycle computer of choice.
RANGE
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
ENERGYPAK 500 / SYNCDRIVE PRO
HIGHLIGHTS
The new Revolt E+ gives you the power to ride from urban streets to rugged rural backroads with efficiency and control. It’s a great way to experience adventure on ever-changing terrain and feel the freedom to extend your range. The reengineered frameset has a new SyncDrive Pro motor that’s powered by Shimano. This customized system delivers smooth acceleration on paved roads, gravel or dirt. New this year is a compact 500Wh battery that lasts 30 percent longer than the previous generation. It also features range extender compatibility, adding another 50 percent battery life to your adventure. The unique SmartAssist motor support smoothly adapts to your riding style automatically and removes the need to adjust the support levels yourself. Manual controls are now cleanly integrated into the brake levers, leaving your cockpit clean and smooth. Wider tires and integrated rack mounts allow you to customize your adventure with fenders, racks or whatever other accessories you desire.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
-
- S
- 5’3”
5’7”
-
- M
- 5’7” 5’11”
-
- L
- 5’10” 6’3”
-
- XL
- 6’2” 6’7”
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (inch) | 17.7 | 18.7 | 20.7 | 21.7 |
| B | SEAT TUBE ANGLE | 73.5° | 73.0° | 73.0° | 73.0° |
| C | TOP TUBE LENGTH (inch) | 21.5 | 21.9 | 22.6 | 23.2 |
| D | HEAD TUBE LENGTH (inch) | 5.3 | 5.9 | 7.1 | 7.7 |
| E | HEAD TUBE ANGLE | 71.0° | 71.0° | 71.0° | 71.0° |
| F | FORK RAKE (inch) | 2 | 2 | 2 | 2 |
| G | TRAIL (inch) | 2.8 | 2.8 | 2.8 | 2.8 |
| H | WHEELBASE (inch) | 41.3 | 41.6 | 42.4 | 43 |
| I | CHAIN STAY LENGTH (inch) | 17.9 | 17.9 | 17.9 | 17.9 |
| J | BOTTOM BRACKET DROP (inch) | 3.3 | 3.3 | 3.3 | 3.3 |
| K | STACK (inch) | 22.6 | 23.1 | 24.2 | 24.8 |
| L | REACH (inch) | 14.8 | 14.8 | 15.2 | 15.6 |
| M | STAND OVER HEIGHT (inch) | 29.2 | 30 | 31.7 | 32.5 |
| N | HANDLEBAR WIDTH (inch) | 15.7 | 16.5 | 16.5 | 17.3 |
| O | STEM LENGTH (inch) | 3.1 | 3.5 | 4.3 | 4.7 |
| P | CRANK LENGTH (inch) | 6.7 | 6.7 | 6.7 | 6.7 |
| Q | WHEEL SIZE | 700C | 700C | 700C | 700C |
