EXTRA TRAVEL, EXTRA FUN. FROM ROWDY ENDURO RUNS TO BACKCOUNTRY MISSIONS ON STEEP, CHUNKY SINGLETRACK, THIS NEW COMPOSITE 29ER BUILDS ON THE TRANCE 29 PLATFORM WITH BEEFED UP SUSPENSION AND ADJUSTABLE FRAME GEOMETRY.

This new member of the Trance family is designed with a longer travel suspension setup for added control on the most challenging trails. The full composite frame is engineered for 135mm of rear travel and 150mm up front. The Maestro rear suspension has a two-stage adjustable Advanced Forged Composite rocker arm with a trunnion-mount shock. The flip-chip equipped rocker arm lets you adjust frame geometry for your own riding style and terrain. To fine tune the ride, you can choose a steeper or slacker headtube angle (66.2 or 65.5 degrees) and seattube angle (77.9 or 77.2 degrees), which results in either a 30mm or 40mm bottom bracket drop. And it’s all built around 29-inch wheels for added stability on rugged terrain.

KEY PERFORMANCE FACTORS

29er confidence and control

Optimized Maestro suspension for 29-inch wheels with 135mm rear/ 150mm front travel to roll over rough terrain with balance and stability, giving you more momentum for technical climbs and the confidence to fly on fast, rugged singletrack descents. Added clearance for up to 2.5-inch tires.

Full Composite Construction

Mainframe and rear swingarm are engineered with proprietary material featuring high-performance carbon fiber and resin. Handcrafted monocoque construction makes it lightweight, stiff and compliant.

Adjustable frame geometry

Flip chip lets you change the headtube and seattube angles, along with the bottom bracket height, to fine-tune the handling. You can choose the low position (65.5/77.2 head/seattube angle and 40mm BB drop) for faster, open terrain or high (66.2/77.9 head/seattube angle and 30mm drop) for slower, tighter singletrack.

Specs

Sizes

S, M, L, XL
Colors

Chrysocolla/Astral Aura/Chrome
Frame

Advanced-Grade Composite front and rear triangles, 135mm Maestro suspension, flip chip
Fork

Fox 36 Factory Live Valve, 150mm, FIT4 damper, Boost 15×110 Kabolt, 44mm offset, custom tuned for Giant
Shock

Fox Float DPX2 Factory Live Valve, 185/55, custom tuned for Giant
Handlebar

Giant Contact SLR Trail, composite, 35
Stem

Giant Contact SL 35
Seatpost

Fox Transfer Factory dropper with Shimano remote, 30.9
Saddle

Giant Romero SL, SST rails
Pedals

N/A
Shifters

Shimano Deore XT
Front Derailleur

N/A
Rear Derailleur

Shimano Deore XTR, Shadow+
Brakes

Shimano Deore XT hydraulic 4-piston (F:203mm, R:180mm)
Brake Levers

Shimano Deore XT
Cassette

Shimano Deore XT, 12-speed, 10×51
Chain

Shimano Deore XT
Crankset

Shimano Deore XT, 30t with MRP AMG V2 Carbon guide
Bottom Bracket

Shimano, press fit
Rims

Giant TRX-1 29 Carbon WheelSystem, 30mm inner
Hubs

Giant TRX-1 29 WheelSystem, Boost
Spokes

Giant TRX-1 29 WheelSystem, DBL technology
Tires

[F] Maxxis Minion DHF, tubeless, 29×2.5, WT, 3C, MaxxTerra, EXO, TR [R] Maxxis Dissector, tubeless, 29×2.4, WT, 3C, MaxxTerra, EXO, TR
Extras

Tubeless prepared
Weight

The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
