LIGHT, EFFICIENT AND FLAT-OUT FAST. WHEN THE CLIMBS ARE STEEP AND THE SPEEDS ARE HIGH, THIS IS THE WEAPON OF CHOICE FOR XC PROS LIKE TWO-TIME MTB MARATHON WORLD CHAMP LEO PÁEZ.
KEY PERFORMANCE FACTORS
Superlight and responsive
Pro-level Advanced SL composite frame is the lightest off-road frame Giant has ever produced, offering serious XC racers a competitive advantage for climbing, accelerating and sprinting.
Ultra-efficient
The frame is engineered with the highest stiffness-to-weight-ratio of any hardtail mountain bike in its class, which translates to ultra-efficient pedaling power and precise handling on the trail.
Custom compliance
Each frame is custom-tuned based on its size. Individual composite lay-up schedules are created to optimize vertical compliance to produce a smoother ride quality on XC terrain.
-
SizesS, M, L, XL
-
ColorsChameleon Galaxy / Starry Night
-
FrameAdvanced SL-Grade Composite, 12x148mm thru-axle
-
ForkRockShox SID SL Select, 100mm, Charger 2 RL damper, 44mm offset, 15×110 Maxle Stealth, remote lockout
-
ShockN/A
-
HandlebarGiant Contact SLR XC Flat, 760x35mm
-
GripsGiant XC Pro S:32mm, M:32mm, L:34mm, XL:34mm
-
StemGiant Contact SL XC 35 S:60mm, M:70mm, L:80mm, XL:90mm
-
SeatpostGiant Contact Switch dropper, Shimano remote S: 125mm travel / 30.9 x 395mm M: 125mm travel / 30.9 x 395mm L: 125mm travel / 30.9 x 395mm XL: 125mm travel / 30.9 x 395mm
-
SaddleFi’zi:k Antares R5 with K:ium rails
-
PedalsN/A
-
ShiftersShimano Deore XT M8100, 1×12
-
Front DerailleurN/A
-
Rear DerailleurShimano Deore XT M8100
-
BrakesShimano Deore XT BR-M8100, hydraulic, Shimano RT-66 rotors [F]180mm, [R]160mm
-
Brake LeversShimano Deore XT BL-M8100
-
CassetteShimano Deore XT M8100, 10×51
-
ChainKMC X-12
-
CranksetPraxis Girder Carbon Boost, 32t S:170mm, M:175mm, L:175mm, XL:175mm
-
Bottom BracketShimano, press fit
-
RimsGiant XCR 1 29 Carbon WheelSystem
-
HubsGiant XCR 1 29 Carbon WheelSystem
-
SpokesGiant XCR 1 29 Carbon WheelSystem
-
TiresMaxxis Rekon Race 29×2.25, foldable, TLR, EXO, tubeless
-
Extrastubeless prepared, 2.25″ max tire size, 38t max chainring size
-
WeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
HIGHLIGHTS
With World Cup pedigree and a progressive frame design, this is the lightest off-road machine ever built by Giant. The chassis is handcrafted with pro-level Advanced SL composite, featuring geometry made to optimize its fast-rolling 29-inch wheels. Every frame is custom assembled with a specific composite layup schedule that varies according to frame size. The result is supercharged climbing efficiency, smooth handling through roots, rocks and ruts, and uncompromising performance to match your XC obsession.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
-
- S
- 5’4”
5’8”
-
- M
- 5’7” 5’11”
-
- L
- 5’10” 6’2”
-
- XL
- 6’2” 6’6”
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (inch) | 15 | 17 | 18.7 | 20.7 |
| B | SEAT TUBE ANGLE | 73.5° | 73.5° | 73.5° | 73.5° |
| C | TOP TUBE LENGTH (inch) | 23.4 | 24.2 | 25 | 26.2 |
| D | HEAD TUBE LENGTH (inch) | 3.7 | 3.7 | 4.1 | 4.5 |
| E | HEAD TUBE ANGLE | 69.5° | 69.5° | 70.0° | 70.0° |
| F | FORK RAKE (inch) | 1.7 | 1.7 | 1.7 | 1.7 |
| G | TRAIL (inch) | 3.7 | 3.7 | 3.7 | 3.7 |
| H | WHEELBASE (inch) | 42.8 | 43.5 | 44.4 | 45.6 |
| I | CHAIN STAY LENGTH (inch) | 16.7 | 16.7 | 16.7 | 16.7 |
| J | BOTTOM BRACKET DROP (inch) | 2.3 | 2.3 | 2.3 | 2.3 |
| K | STACK (inch) | 23.8 | 23.8 | 24.1 | 24.9 |
| L | REACH (inch) | 16.4 | 17.1 | 17.8 | 18.8 |
| M | STAND OVER HEIGHT (inch) | 29 | 30.1 | 31.1 | 32.6 |
| N | HANDLEBAR WIDTH (inch) | 29.9 | 29.9 | 29.9 | 29.9 |
| O | STEM LENGTH (inch) | 2.4 | 2.8 | 3.1 | 3.5 |
| P | CRANK LENGTH (inch) | 6.7 | 6.9 | 6.9 | 6.9 |
| Q | WHEEL SIZE | 29″ | 29″ | 29″ | 29″ |
